The One Tesla Upgrade You Didn't Know You Needed
The Tesla Model 3 and Model Y have redefined the modern automotive interior with their minimalist design, dominated by a single, monolithic 15-inch central touchscreen. It’s the command center for everything from navigation and climate control to entertainment. Yet, for all its futuristic appeal, it has one fundamental limitation: it’s fixed. Every Tesla owner has experienced the frustration of sun glare washing out the map, or the awkward neck crane required for a passenger to co-pilot the navigation. What if you could solve this ergonomic oversight with a simple, elegant upgrade?
Enter the Tesery Screen Rotating Bracket for Tesla Model 3/Y. This brilliantly engineered accessory transforms your static display into a dynamic, adjustable interface. It’s a modification that feels less like an aftermarket add-on and more like a feature that should have come standard from the factory. In this detailed guide, we'll follow along with Haluking from the Tesla Boy Channel as he unboxes, installs, and reviews this game-changing accessory, providing you with everything you need to know to perform this upgrade yourself.
Why a Swivel Screen is a Non-Negotiable Upgrade
Before we dive into the installation, let's explore the core problems this mount solves. The fixed screen, while aesthetically clean, presents several daily usability challenges.
- Sun Glare: Depending on the time of day and your direction of travel, the sun can render the screen nearly unreadable. A simple tilt or swivel can instantly eliminate this glare, improving both visibility and safety.
- Driver Ergonomics: The ability to angle the screen slightly toward the driver creates a more focused and comfortable command center. It reduces eye strain and makes interacting with the screen feel more natural and intuitive.
- Passenger Experience: Whether your co-pilot is managing the music, looking up a destination, or you're both watching a movie while charging in "Theater Mode," a screen that can face the passenger is a massive quality-of-life improvement.
- A Premium Feel: High-end vehicles from other brands often feature adjustable screens. Adding this functionality to your Tesla elevates the cabin experience, giving it a more luxurious and user-centric feel.
First Impressions: Unboxing the Tesery Kit
As Haluking unboxes the kit, the immediate takeaway is quality. This isn't a flimsy plastic part; it's a comprehensive, well-thought-out solution. The centerpiece is the articulating arm itself, a heavy-duty bracket made of solid cast metal. Its weight and robust construction inspire confidence that it can securely support the expensive touchscreen without any wobble or vibration.
Accompanying the metal bracket are the new housing covers. Tesery has meticulously crafted these from a matte black plastic designed to perfectly match the texture and color of the existing Tesla dashboard trim. This attention to detail ensures that once installed, the mount looks like an original factory component. The kit also includes every tool required for the job: a plastic pry tool to avoid scratching the trim, a socket wrench with an extension for the deep-set bolts, and the necessary L-shaped Torx and hex keys. This all-in-one approach makes the DIY process accessible even for those with limited mechanical experience.
A Comprehensive Guide to Installing Your Tesery Screen Mount
Following the video, we can break down the installation into a series of clear, manageable steps. The entire process is straightforward, but precision and care are key.
Important Safety Note: Before you begin any work, the most critical step is to power down the vehicle completely. Navigate to 'Safety' on your touchscreen and select 'Power Off'. Wait a few minutes for all systems to shut down. During the installation, avoid touching the brake pedal or opening the doors, as this can wake the vehicle and send power back to the screen.
Step 1: Gaining Access to the Factory Mount
The first step is to remove the small plastic cover located behind the screen, which houses the cabin temperature sensor. Using the included orange pry tool, gently work around the edges of this cover. You'll hear the satisfying click of the clips releasing as it pops off, revealing the sensor and the two bolts that hold the screen in place.
Step 2: Uninstalling the Original Screen
Using the provided socket wrench, carefully loosen and remove the two 10mm factory bolts. As Haluking notes, don't be alarmed if you see small metal shavings fall onto your floor mat. Tesla uses a strong thread-locking compound on these bolts from the factory, and removing them scrapes some of this material off. It's completely normal.
Step 3: Disconnecting the Cables
With the bolts removed, gently pull the screen forward to access the two cable connections on the back. The main display cable uses a distinct purple and pink "Fakra" style high-speed data connector. It has a small release tab that needs to be pressed to unplug it. The second, smaller cable is for the temperature sensor. Disconnect both and carefully set your screen aside on a soft, protected surface.
Step 4: Installing the Tesery Rotating Arm
Now, it's time to install the new articulating arm. The video points out a helpful detail: the arm is marked with an "R" to indicate the right side, ensuring correct orientation. Position the heavy-duty metal arm and start threading the bolts by hand. Before tightening them down completely, make sure the base of the arm is sitting perfectly flush against the dashboard mount. This prevents any alignment issues later on. Once it's flush, tighten the bolts securely.
Step 5: Reassembly and Final Touches
The reassembly process is the reverse of the disassembly. Mount the screen onto the new bracket using the supplied hardware. Reconnect the main purple Fakra connector and the temperature sensor cable, ensuring they click securely into place. Next, transfer the small cylindrical temperature sensor from the old plastic housing to the new Tesery housing. Finally, snap the new matte black cover into place. The precise fit and matching texture create a seamless, OEM-quality finish.
The Final Verdict: A Transformed Driving Experience
With the installation complete, the difference is immediate and dramatic. The screen now glides smoothly, offering a wide range of horizontal and vertical adjustments. Haluking demonstrates how easily he can tilt it to eliminate glare or swivel it towards the passenger. He does note one small change in positioning: the screen now sits slightly higher and further forward. While this might minimally obscure the view of the wireless phone charger from certain angles, he concludes it's a positive trade-off, as it brings the screen closer and improves overall visibility for the driver.
The Tesery Screen Rotating Bracket for Tesla Model 3/Y is more than just an accessory; it's a fundamental enhancement to your Tesla's interior. It addresses a key design compromise and unlocks a new level of comfort, convenience, and functionality. For a relatively simple DIY project, the payoff in daily usability is immense, making this one of the most highly recommended upgrades for any Model 3 or Model Y owner. Don't forget to use the coupon code haluking for a special discount on your purchase!
